Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: Chuangrui
  • Model Number: SG600FC
  • Theory: peristalitc pump
  • Structure: peristaltic pump
  • Usage: juice transfer and filling
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: electrial
  • Pressure: Low Pressure
  • Application: juice filling pump
  • Model: SG600FC
  • Pump head: yz35 yz35-13
  • Rotation Speed: 0.1-600 Rpm
  • Flow rate: 1.3-12000 ml/min
  • Foot pedal: Yes
  • Direction: reversible
  • Tube: Silicon tube
  • Resolution: 0.1 rpm
  • Weight: 21 Kg
  • MOQ: 1 Set

Packaging & Delivery

Packaging Details Reliable thick foam wrapped, standard export carton, waterproof film
Delivery Time 7 days
Product Description

0-500 ml jam and juice constant filling peristalitc liquid filling pump

SG600FC peristaltic liquid pump  has touch-sensitive color LCD screen to display the Run and parameter setting menu, filling parameters and flow’s display is simple and intuitive, easy operation. It also has flow calibration function, when the filling volume deviation through this calibration, in order to meet the requirements of the users of high-precision filling. With a variety of control methods, with the communication interface to provide users with communication protocol, users can request custom PC software for remote control.

Features of peristaltic pumps:

Non-pollution

No need cleaning

Low shear force

Maintenance convenient

Wide application


Model
SG600FC
Revolving speed range
0.1-600 rpm
Speed resolution
0.1 RPM
Flow rate range
1.3-12000 ML/MIN
Speed error
<0.5%
Control method
Touch screen and keypad
Display
3.5 inch LCD  Touch screen
Copy number
1-9999  times
Dispense volume:
0.1 ml-99.9 L
Intervals
0.1 sec- 9999 min
Copy time
0.1sec--9999 min
Power supply
AC220V±10% (standard); or AC110V±10% (optional).
External control
Analog control(0-5V, 0-10V, 4-20mA to be optional)
RS485 communication interface
Environment temperature
0-40℃; Relative humidity <80%; without condensation.
IP Protection grade
31
Tube
ID mm
OD mm
Max speed(rpm )
Max flowrate (ml/min)
73#
9.6
16.2
600
7400
82#
13
19.6
600
12000
Order guide

Dear All ,

Welcome to our website ,wish you have a nice day and will get the harvest from us .=))

To help you choose the suitable pump. can you help me to confirm some details as below :

1,what's the application of the pump ? bottle filling or constant transfer ?

2,what kind of liquid you will transfer ? does it corrosive ? does it can flow as water ?

3, for constant transfer ,what's flowrate you need? ml/min

4, for bottle filling ,what's your bottle's volume ? ml How many bottles you want to filling in 1 min ?

Pls send these answers or most details to us, then we will help u to choose the best pump and tube .

Thanks for your time .

Contact : Ella Xu

whatsapp :+0086 15633705132 skype : ella-crpump QQ :507183200

FAQ

Question 1: Can I order custom peristaltic pump with my own design & logo?

Answer: Definitely yes.

Question 2: Can I order a sample first before mass production? How can I place a sample order?

Answer: Surely you can order a sample first. And there will be some sample cost, charged based on your design. We will make the sample pump for you after payment received and take pictures for your reference once finished. If you want to see the actual sample, we can send the sample to you while freight cost is yours.

Question 3: How soon can I get a sample made? How can I make payment?

Answer: For simple design sample, it generally takes about 7-15 days to get samples made. While it will take a longer time for design, make a mold, assemble, actual test. etc. Payment can be made through T/T, paypal or Western Union.

Question 4: How can I get my peristaltic pump if I place the order to you?

Answer: That depends on the quantity your ordered. 1 to 100 pieces, the pumps will be shipped to you by express(DHL, Fedex, etc.); 100 or more, mostly by air or by sea.

Question 5: Can I buy the tube separately?

Answer: Of course Yes. for the silicone tube 15 meters per roll, or you can buy 1 or 2 meters. No problem.

Why choose us

Baoding Chuangrui Precision Pump Co., Ltd.

1,10 years Design and production experience of peristaltic pump .
2,Redesigned for you the ideal OEM customized solutions
3,A strong technical team
4, Very perfect service system , at 24 hours service .
